17 | The two-way powered swivel seat (Q4 2021)
The powered swivel operates when the directional safety line is interrupted.
The powered swivel does not operate when the general safety line is interrupted.
The powered swivel seat does not swivel
• The lift is making its first ride since calibration
•
Wire break between K3-6/K3-5 and C22/E22
•
Break in the motor wiring
•
Defective motor end switches
•
The powered swivel is not activated on the data card
• The general safety line (final limit switch, e-stop, keyswitch) is interrupted
The powered swivel seat does not stop in the centre postion and swivels towards the stairs
•
The sensor C24/E24 is defective
The powered swivel seat only swivels in one direction
•
A diode or a motor endswitch is defective
The powered swivel seat swivels towards the stairs
•
Check the dipswitch setting on the swivel option printed circuit
•
Change the red and the green wire on C22/E24
The lift starts only after two commands from the remotes
•
Check the dipswitch setting on the swivel option printed circuit
