8 | The Charger
An indicator lamp is fitted to the front of the battery charger:
•
Red: the chair lift's batteries are charging with high voltage
•
Orange: the chair lift's batteries are charging with low voltage
•
Green: the chair lift's batteries are dripped charged
Consequently the indicator lamp should always be red when the chair lift stops at the charging
station after a trip.
In due course the lamp turns green, indicating that the batteries are charged.
The battery charger is suited to an input voltage of between
100V~ and 240V~.
The output voltage is between 27,4 V= and 27,7 V= when the stairlift is not
charging.
The output voltage is between 28,6 V= and 29,1 V= when the stairlift is
charging.
The charging current is 1.5 Amp.
