2.10 LIMITS OF USE AND NON-PERMITTED USES
The machine was designed and built exclusively for the uses described in the technical manual.
Any other use is prohibited as it could generate risks for the health of operators and users.
However, the unit is not suitable to be operated in environments:
• where there are vibrations;
• where electromagnetic fields are present;
• in which aggressive atmospheres are present.
THIS UNIT IS NOT SUITABLE FOR OPERATION IN EXPLOSIVE ATMOSPHERES.
2.11 IDENTIFICATION OF THE UNIT
Each unit is equipped with a plate fixed to the outside of the same, which shows the identification data of the machine
and the main technical characteristics. For electrical information not present on the label, refer to the wiring diagram.
Check that the characteristics of the electrical network comply with the data shown on the identification plate. A FAC-
SIMILE of the plate is shown below with the relative legend of the data reported on it:
8
1
11
2
4
5
3
6
9
KEY:
(1) Model
(2) Electrical power supply characteristics
(3) Nominal air flow
(4) Electrical power absorbed
(5) Max electric current absorbed
(6) Weight of the basic unit
The identification label must never be removed from the unit.
44
indicative measure indicative measure
Via dell'Industria, 2/4, 31029
Vittorio Veneto TV. ITALY
T:0438 500044 info@tecnosystemi.com
HEAT RECOVERY VENTILATION UNIT
Part Number: ACD300002
Model:
Model name
Batch:
Production batch reference
Supply: 230V - 50Hz
Power: 80W
Working Temperature: 0T50°C
Air Flow: 250 m³/h
Weight: 25Kg
Year: 2023
100 100
IP22
10
(7) EAN code
(8) Unit item code
(9) Year of manufacture
(10) IP Rating
(11) Production batch
7
