Be careful when lifting the unit whose centre of gravity may also be very unbalanced;
•
Be careful when locking the lifting ropes/hooks;
•
Pay attention to the sheet metal edges inside the unit;
•
Pay attention to the sheet metal edges on the outside of the unit;
•
Pay attention to possible burns deriving from heating coils;
The machine has been designed in such a way as to minimise risks to the safety of persons who will be interacting with
it. During the project it was not technically possible to completely eliminate the causes of risk. Therefore it is absolutely
necessary to refer to the following instructions and symbols.
COMPONENTS
CONSIDERED
(if present)
Mixing chamber with
shutters and servo
commands
Recovery unit
Fans
Unit exterior: area
surrounding the unit
Inside the unit: electrical
cables and metal parts
42
RESIDUAL RISK
Crushing
Small cut injuries,
crushing
Injuries
Intoxications,
severe burns
Electrocution,
severe burns
INJURY METHOD
Contact
Contact
Insertion of objects
while the fans are
in operation
Fire due to short circuit
or overheating
of the power line
upstream of the unit's
electrical panel
Insulation defect of
power cables, live
metal parts
PREVENTION
AND PROTECTION
Remove voltage before any
operation
Avoid contact,
use protective gloves
Do not insert objects of
any kind into the ventilating
sections
Section of the cables
and protection system
of the power supply
line complying with the
standards in force.
Adequate electrical
protection of power lines;
utmost care in carrying out
the earth connection of the
metal parts
