Prayer Clock - Single Line Diagrams

The Prayer Clock comes pre-programmed with Third-Party NTP Time Servers and a Prayer Time
Server accessible via the facility's network (LAN) and internet connection.
Hard-Wired IP clocks interface with the facility's network over a standard network cable (CAT5/6),
while Wi-Fi clocks interface with the facility's network over Wi-Fi signal. Sapling Prayer Clock Line Drawings
Hard-Wired IP Prayer Clock
Router
Router
Modem
Modem
Prayer Times Server Third-Party NTP
Prayer Times Server Third Party NTP Time
Servers
Time Server
Wi-Fi Prayer Clock
Local Power
(110 - 230 VAC)
