Sapling Prayer Clock Installation Manual page 13

Hard-Wired Network Clock Configuration
Each clock/display is already named to reflect either local time or the prayer name displayed. As such,
there is no need to rename a clock/display unless for a specific application. To change each clock
(display) name or other settings, there is a need to access the clock built-in web interface. This can
be done by double clicking on a clock name in the Network Monitoring Software. The default login
password is: 6063
Double click on
the clock (display)
you would like to
program
Specific clock built-
in web interface
Serial Number: 28083
MAC: 60:36:96:28:1f:93
Serial Number: 11532
MAC: 60:36:96:0a:05:fc
Serial Number: 11533
MAC: 60:36:96:0a:05:fd
Serial Number: 11531
MAC: 60:36:96:0a:05:fb
Serial Number: 11525
MAC: 60:36:96:0a:05:f5
Serial Number: 11529
MAC: 60:36:96:0a:05:f9
Serial Number: 11530
MAC: 60:36:96:0a:05:f0
The Sapling Company, Inc. The Sapling Company, Inc.
670 Louis Drive 670 Louis Drive
Warminster, PA 18974 Warminster, PA 18974
USA USA
Clock (display) name is Local Time
Clock (display) name is Fajr
Clock (display) name is Shuruq
Clock (display) name is Dhuhr
Clock (display) name is Asr
Clock (display) name is Maghrib
Clock (display) name is Isha
(6th clock/display optional)
6063
P. (+1) 215.322.6063 P. (+1) 215.322.6063
F. (+1) 215.322.8498 F. (+1) 215.322.8498
www.sapling-inc.com www.sapling-inc.com
13 13
