Wi-Fi Network Clock Configuration
As explained, each clock/display is already programmed with its designated name, allowing the user to
easily identify the clock/display using the Network Monitoring Software. Please also note that behind
the clock's back panel are labels listing each clock's (display's) serial number and MAC address in order
from top to bottom, correlating with the 12" square clock being on top, going down, as shown in the
below image.
Knowing each clock's (display's) name, serial number and MAC address will allow the user to easily identify
each clock (display) appearing on the list of Wi-Fi networks and the Network Monitoring Software.
1. On a Wi-Fi enabled computer, check the available Wireless Networks and look for the Wi-Fi signal
transmitted by the clocks (displays). Refresh the available Wi-Fi networks until network names shown
below appear:
Local Time, Fajr, Shuruq, Dhuhr, Asr, Maghrib, Isha
Since each clock/display should transmit its own hotspot for initial programming, you will see a
different Wi-Fi hotspot for each clock/display. The Wi-Fi hotspot transmitted by each clock/display
should appear within 30 seconds.
2. Once these appear, identify each clock based on its name. Connect to the network of the clock you
would like to set first.
3. Open a web browser and enter the following web address into the URL field:
http://192.168.240.1/login.html
Doing so will take you to the clock (display) built-in web interface, as shown in the below image.
Serial Number: 28083
MAC: 60:36:96:28:1f:93
Serial Number: 11532
MAC: 60:36:96:0a:05:fc
Serial Number: 11533
MAC: 60:36:96:0a:05:fd
Serial Number: 11531
MAC: 60:36:96:0a:05:fb
Serial Number: 11525
MAC: 60:36:96:0a:05:f5
Serial Number: 11529
MAC: 60:36:96:0a:05:f9
Serial Number: 11530
MAC: 60:36:96:0a:05:f0
6063
Login Page
The Sapling Company, Inc.
670 Louis Drive
Warminster, PA 18974
USA
Clock (display) name is Local Time
Clock (display) name is Fajr
Clock (display) name is Shuruq
Clock (display) name is Dhuhr
Clock (display) name is Asr
Clock (display) name is Maghrib
Clock (display) name is Isha
(6th clock/display optional)
Home Page
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
18
