Powering the Clock

The clock is designed to be hard-wired to local power at 100-230 VAC. Its power port is located

behind the lower back panel as shown in the below image.

Open and remove the clock's lower back panel by using a Phillips screwdriver. Behind the panel, there

is an electric board with a phoenix type electrical connector dedicated for local power wires. Since

initially the clock is powered only for preliminary setup, the local power electrical wires can be screwed

directly to the electrical connector, as shown in the below image (at this stage, there is no need to

thread the power wires via the back panel).

Back of clock

*Port 1 is designated for electrical wires

*Port 2 is designated for an ethernet cable

*Ports 3 and 4 are designated for optional

accessories

Clock back ports panel

The Sapling Company, Inc.

670 Louis Drive

Warminster, PA 18974

USA

*Port 1

*Port 2

*Port 3

*Port 4

Prayer Clock Electric Board

Local Power (Phoenix

type) connector
