Optional Network Configuration - Sapling Prayer Clock Installation Manual

Optional Network Configuration – for both IP Hard-Wired and Wi-Fi
This section will include instructions on how to program optional settings. The settings are the same for
both the Wi-Fi clocks (displays) and for the IP hard-wired clocks (displays); however, their built-in web
interface looks slightly different. Therefore, you will see the same instructions for both types of network
clocks (displays) with a split page showing images of the built-in web interface for the IP hard-wired clocks
(displays) on one side, while the images of the built-in web interface for the Wi-Fi clocks (displays) will be
shown on the other side.
Display Settings (FOR DIGITAL DISPLAYS ONLY):
In the "Display Settings" tab for both Hard-Wired IP clocks and Wi-Fi clocks, the user can set optional display
settings, such as the display format and brightness settings, as shown in the below images.
1. Display Format - Allows the user to select how the time is displayed on the clock. There are two
options: 12 hour format (3:00AM/3:00PM) or 24 hour format (3:00/15:00).
2. Brightness - Sets the brightness level that the clock will display. There are four levels to choose from:
High, Medium, Low or Off.
3. Brightness Schedule - When the button is pressed, the user is taken to the Brightness Schedule Page.
Refer to the next section of this manual for further instructions.
When finished, press the "Submit" button at the bottom.
Hard-Wired IP Clocks
1
2
Wi-Fi Clocks
1
2
3
