- Page 1 Installation Manual V1 NTP 7000 Series Master Clock The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com...
-
Page 2: Table Of Contents
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com NTP 7000 Series Master Clock Table of Contents Table of Contents—2-3 Installation Wall Mount Installation —4 Rack Mount Installation —5 Installing the Master Clock with the Line Cord Receptacle—6 AC Power Wiring using 14 AWG Romex Cable—6... - Page 3 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com NTP 7000 Series Master Clock Table of Contents IP—32 NTP Servers—33 IP Status—34 Clock Features—35 Database Maintenance—36 Support Frequently Asked Questions—37 Troubleshooting—38...
-
Page 4: Wall Mount Installation -4
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Wall Mount Installation Fig 1 1. Place the supplied template on the wall where the master clock is being mounted. 2. Mark the center point of the top right hole. Drill the hole and install the supplied anchor from the mounting kit. -
Page 5: Rack Mount Installation -5
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Rack Mount Installation 1. The master clock is 1U in size. Install the threaded nuts in the desired location in the rack rails. -
Page 6: Installing The Master Clock With The Line Cord Receptacle
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Before You Get Started Installing the Master Clock with the Line Cord Receptacle Remainder of cord not shown *220-240 VAC Caution! Do not plug in the power cord until the following steps are completed. -
Page 7: Rear View Of Unit
1. Clock 1 & 2 Sync-Wire Outputs This terminal block is where connections would be landed for Clock 1 and Clock 2 sync-wire communication relay outputs. 2. RS485 Input/Output This terminal block is where connections would be landed for RS485 communication to and from other Sapling systems. -
Page 8: Remote Antenna Mounting Instructions
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Remote Antenna Mounting Instructions 1. Remove the cover of the wiring panel. 2. Mark the four drilling points on the wall based on the drawing above. -
Page 9: Wire Digital Communication System Connection
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com System Connections – Wired Systems 2 Wire Digital Communication System Connection 18 19 110V (EU 240V) 24V SBD 3000 Series Wired Clock... -
Page 10: Rs485 Communication System Connection-10
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com System Connections – Wired Systems RS485 Communication System Connection Black White (EU 240/24VAC) (EU 240/24VAC) Black/Yellow Orange/White 110 / 24V SBD 3200/3300 Series... -
Page 11: Sync-Wire Communication System Connection
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com System Connections – Wired Systems Sync-Wire Communication System Connection (EU 240/24V) (EU 240/24V) Yellow/Blue Black/Yellow White/Orange SBD 3300 Series Wired Clock (EU 240/24V) -
Page 12: Once-A-Day Pulse Using Clock 1 Or Clock 2 System Connection
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com System Connections – Wired Systems Once-a-day Pulse Using Clock 1 or Clock 2 System Connection Clock Circuit Intercom, paging system, or other device... -
Page 13: Minute Correction
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Inputs – Sync-Wire Inputs Installation 59 Minute Correction Dry Contact Closure 110VAC Interface 24VAC Interface (EU 240VAC) N.O. 58 Minute Corrections 1–4... -
Page 14: National Time/Rauland-14
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Inputs – Sync-Wire Inputs Installation National Time/Rauland Dry Contact Closure 110VAC Interface 24VAC Interface (EU 240VAC) Rauland Digital Input Output... -
Page 15: Dukane Digital
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Inputs – Sync-Wire Inputs Installation Dukane Digital Once a Day Pulse Dry Contact Closure... -
Page 16: Fire Alarm Interface Installation
Fire Alarm Interface Installation The Fire Alarm Interface allows a relay closure to be connected to the NTP server that allows the user to interface the existing fire alarm with the Sapling SBD 3000 series digital clocks. N.O. When a relay closure occurs on pins 8 and 9, “FirE” will display on the digital slave clocks connected using RS485 or two wire digital communication. -
Page 17: Gps Antenna Installation
Supplied by Sapling: GPS Dome, a 75’ of RG58 or 150’ length of RG59 cabling (refer to Figure 1.1) Not supplied by Sapling: Steel or PVC piping with 1”-14” thread or 3/4” pipe thread, teflon tape, mounting plate and hardware for piping (refer to Figure 1.1) -
Page 18: Setting The Time From The Led Display
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com User Level Programming Setting the Time from the LED Display To set the time, press the top button to change the hour and/or the bottom button the set the minute. - Page 19 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 3 - Set Day: Use the bottom button to scroll between “01-31”. Option 10 - Technical Mode: If technical mode is desired, press the bottom button until “08” is reached.
- Page 20 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 20 - Programming the Clock #1 Circuit: Press the bottom button to scroll through “1”, “2”, “3”, “4”, “5”, “6”, “7”, “8” & “9”. Please refer to relay selection mode on page 24.
- Page 21 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 25 - Programming the Clock #2 Circuit: Press the bottom button to scroll through “1”, “2”, “3”, “4”, “5”, “6”, “7”, “8” & “9”. Please refer to relay selection mode on page 24.
- Page 22 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 30 - Set the Primary Input: Press the bottom button to scroll between “1-13” to select the input. 00 - Real Time Clock...
- Page 23 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 35 - Once a Day Pulse Input - Set Minutes This option is only available when option 30 or 31 is set to 11. Press the bottom button to scroll through “00-59”.
-
Page 24: Sync-Wire Communication - Protocol Definitions
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Option 50 - Entering Diagnostic Mode Press the bottom button to scroll between “E - d”. Setting the option to “E” will enable the option and will enter diagnostic mode. Setting the option to “d”... -
Page 25: Error Codes On Led Display-25
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Error Codes Error Codes on LED Display When one of the following errors occurs, one of the LED lights located above one of the six characters on the LED display will being to flash. See figure below indicating the error each flashing light is associated with. -
Page 26: Accessing The Web Interface (When Using A Crossover Cable)
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming *The web interface is an optional feature and is not available on all units. *Please make sure that ports 123 and 80 in both directions are open on the firewall. -
Page 27: Web Interface
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Log In 1. Password - There are two levels of passwords that will enable the user to access features. The first level is the user level programming that includes features like setting the time, date, adding and editing events and schedule changes. - Page 28 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Date/Time 1. Time - This field is where the current time is displayed. The time can be edited by clicking within the field, and typing in the desired time. The time must be entered in 24 hour format (HH:MM:SS).
-
Page 29: System Settings
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming System Settings 1. User Password This field allows the user to enter a new password for the user level programming. The password must be entered twice before being changed. - Page 30 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming 1. Daylight Saving Time Selection This drop down list gives four options for Daylight Saving Time: • None - When this option is selected, Daylight Saving Time is not applied at all.
- Page 31 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming Synchronization 1. Input Selection This drop-down list allows the user to select which input will control the master clock. The choices are: •...
- Page 32 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming 1. Gateway IP Address* This field allows the user to set the Gateway IP address for the master clock.
- Page 33 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming NTP Servers 1. Retry Failed-Server After This field allows the user to specify how many times it will attempt to access the time from a server before it moves on to the next one.
- Page 34 The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming IP Status 1. MAC Address This displays the MAC address for the master clock. 2. IP Address This display the IP address for the master clock.
-
Page 35: Clock Features
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming Clock Features 1. Display Format This drop-down list allows the user to select whether they want 12 hour or 24 hour mode to be displayed on the LCD and LED. -
Page 36: Database Maintenance
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Programming Database Maintenance 1. Upload Database This button, when pressed, will upload the configuration of the master clock, and place it in a file for backup purposes. -
Page 37: Frequently Asked Questions
The NTP master clock can accept an input from a SNTP server, 59 minute correction, four different versions of the 58 minute correction, National Time/Rauland, Dukane digital, Rauland digital, Sapling Wireless Repeater, Once a Day pulse, GPS and Sapling’s RS485 protocol. -
Page 38: Troubleshooting
The Sapling Company, Inc. (+1) 215.322.6063 P. 1633 Republic Road (+1) 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Support Troubleshooting The master clock will not power up. What do I do? Make sure the power cord is securely connected to the power outlet and to the back of the NTP master clock. Upon being connected to power, the master clock should boot up instantly. - Page 39 CET appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. CE Declaration of Conformity We, The Sapling Company certify and declare under our sole responsibility that the NTP 7000 conforms with the essential requirements of the EMC Directive 2004/108.EC and LVD 2006/95/EC, based on the following standards applied:...
