Design and function
TIG welding task definition
5.1.14 Connection for workpiece lead
Item Symbol
1
2
•
Insert cable plug on the workpiece lead into the connection socket for workpiece lead and lock by turn-
ing to the right.
5.2
TIG welding task definition
The user defines the welding tasks using JOB numbers.
Each JOB number stores all the parameters relating to the welding task.
The user can either load an existing JOB, load an existing JOB and change it, or define a completely new
JOB via the various interfaces.
38
Description
0
Workpiece
Connection socket, "+" welding current
Workpiece connection
Figure 5-14
Figure 5-15
099-000140-EW501
