5.2.10 Expert menu (TIG)

The Expert menu has adjustable parameters stored that don't require regular setting. The number of pa-
rameters shown may be limited, e.g. if a function is deactivated.
Display
099-000140-EW501
30.01.2024
4 s
4 s
Setting/selection
Expert menu
Slope time (main current to secondary current)
Slope time (main current to secondary current)
Amplitude balance > see 5.2.5.3 chapter
Parameter activArc > see 5.2.8 chapter
Setting the intensity
Filler wire process (cold wire/hot wire)
-------Filler wire disabled (factory setting).
-------Filler wire enabled (additional parameters are indicated).
Hot wire process (start signal for hot wire power source)
-------Function enabled
-------Function disabled (ex works)
Wire/pulse function (wire feeding behaviour when using pulsed TIG welding)
Wire feeding can be disabled during pulse pauses (not the case for automated pul-
sing or kHz pulsing).
-------Function disabled
-------Function enabled (ex works)
Design and function
Figure 5-38
TIG welding task definition
