9

Accessories

Performance-dependent accessories like torches, workpiece leads, electrode holders or
intermediate hose packages are available from your authorised dealer.
9.1

System components

9.1.1

Media separation box

Type
TIG TORCH BOX
9.1.2

Welding torch cooling system

Type
RK1
RK2
RK3
cool82 U44
cool82 U45
9.2

Connection cables, connection sockets

Type
32A 5POLE/CEE
RA5 19POL 1x 5M
RA10 19POL 1x 10M
9.3

Transport system

Type
PALETTE ROB XX2
TROLLY ROB XX2
9.4

Options

9.4.1

Option for retrofitting

Type
BGA364X51X47
ON FILTER XX2
ON STACK XX2
9.4.2

Option for conversion

Risk of injury and equipment damage due to inadequate training!
The conversion options listed below generally involve opening the device. An opened
machine poses various dangers (e.g., electrical voltages, hot coolant, etc.). Dangerous
voltages can still be present in power sources even after they have been switched off.
• Only knowledgeable, qualified service personnel with appropriate training may carry out
conversions.! Qualified people are those who, based on their training, knowledge and expe-
rience, can recognise the hazards and possible consequential damage that arise when tes-
ting welding power sources and take the necessary safety precautions. The unauthorised
intervention will void the warranty.
Type
ON Key Switch
099-000140-EW501
30.01.2024
Designation
TIG media separation box, SCO
Designation
Reverse cooling unit
Reverse cooling unit
Reverse cooling unit
Cooling unit for robot machines
Cooling unit for robot machines
Designation
Machine plug
Connection cable, 19-pole, one-sided wire end slee-
ves
Connection cable, 19-pole, one-sided wire end slee-
ves
Designation
Transport pallet for use with robots
Transport vehicle for a power source with an add-on
module
Designation
Panel for stacking machines
Dirt filter for air inlet for robot power sources
Connection set for stacking welding machines
CAUTION
Designation
Optional retrofit kit for key switch
Accessories
System components
Item no.
090-S08299-02716
Item no.
094-002283-00000
094-002284-00000
094-002285-00000
090-008268-00502
090-008280-00502
Item no.
094-000207-00000
092-001569-00005
092-001569-00010
Item no.
090-008275-00000
090-008278-00000
Item no.
094-012294-00001
092-002714-00000
092-007856-00000
Item no.
092-001828-00000
