19-pole connection assignments for mechanised welding interface (X6):
Signal
Pin
shape
A Output
B
Input
C Input
D
Output
E
Input
F Input
G Output
H
Output
J Output
K
Input
L Input
M Output
N
Input
P Input
R
Input
S
Output
T Output
U
Input
V Output
099-000140-EW501
30.01.2024
Circuit diagram sig-
Function
nal name
PE_DYN Connection for cable screen
Pulsen ein Thermal pulse mode up to max. 50 Hz, fixed balance of
50%
SYN_E Synchronisation for master/slave operation
IGRO Relais Current flows signal
I > 0
Contact closed = welding current flowing
(forms contact with signal G)
Not/Aus Emergency stop for higher level shut-down of the power
source.
To use this function, jumper 1 must be unplugged on PCB
T320/1 in the welding machine.
Contact open  welding current switched off
Sollwert Absenkstrom Control voltage specification for secondary current,
0-10 V (0 V = I
IGRO Relais Current flows signal
I > 0
Contact closed = welding current flowing
(forms contact with signal D)
Prozeßspannung Uist Actual welding voltage, measured on pin S,
0-10 V (0 V = 0 V, 10 V = 100 V)
SYN_A E Synchronisation for master/slave operation
SYN_A C
Str./Stp. Start/stop welding current, same as torch trigger.
Only available in non-latched operating mode.
+15 V = Start, 0 V  Stop
+15V Power supply
+15 V, max. 75 mA
Sollwert Hauptstrom Control voltage specification for main current,
0-10 V (0 V = I
Sollwert Frequenz Nominal frequency value
0-10 V (0 V= 50 Hz, 10 V = 0.1 Hz)
Not/Aus Emergency stop for higher level shut-down of the power
source.
To use this function, jumper 1 must be unplugged on PCB
T320/1 in the welding machine.
Contact open  welding current switched off
0V Reference potential
Prozessstrom Iist Welding current, measured on pin S,
0-10 V (0 V = 0 A, 10 V = 1000 A)
BR. KOLL. 1 Emergency shut-down collision protection +24 V
BR. KOLL. 2 Emergency shut-down collision protection
Design and function
Interfaces for automation
/10 V = I )
min
max
/10 V = I )
min
max
