Rectifying faults
Error messages
Error Possible cause
Error in the emergency stop circuit
(interface for automated welding)
5 Overvoltage
6
Undervoltage
7 Coolant error (with connected coo-
ling unit only).
8
Gas error
9 Secondary overvoltage
10 PE error
11
FastStop position
12 VRD error
16
Pilot arc fault
17 Filler wire error
Excess current or deviation of the
actual value from the wire target va-
lue.
18 Plasma gas error
Target value specification deviates
significantly from the actual value.
19 Shielding gas error
Target value specification deviates
significantly from the actual value
20 Coolant flow
Coolant flow rate too low
22 Excess temperature in cooling circuit Check cooling circuit (coolant level, temperature target
23
Excess temperature of the HF choke Allow the machine to cool. Adjust processing cycle
24 Pilot arc ignition error
32
Electronics error (I>0 error)
33 Electronics error (Uact error)
34
Electronics error (A/D channel error)
35 Electronics error (slope error)
36
Electronics error (S sign)
37 Electronics error (temperature error) Allow the machine to cool.
38
---
39 Electronics error (secondary overvol-
tage)
40 Electronics error (I>0 error)
48
Ignition error
49 Arc interruption
51 Error in the emergency stop circuit
(interface for automated welding)
57
Auxiliary drive error, tacho error
59 Incompatible component
78
Remedy
Check the external shutdown devices. Check the jum-
per JP 1 on PCB T320/1.
Switch off the machine and check the mains voltage.
Check coolant level and top up if necessary.
Check the gas supply.
Switch the machine off and on. If the error persists, no-
tify Service.
Slope "Acknowledge error" signal (0 to 1) using the ro-
bot interface (if present).
Switch the machine off and on. If the error persists, no-
tify Service.
Check welding torch.
Check the wire feed system (drives, hose packages,
welding torches, process wire feed speed and robot
travel speed) and correct if necessary.
Check plasma gas supply (leak tightness, kinks, guide,
connections, closure).
Check plasma gas supply (leak tightness, kinks, guide,
connections, closure).
Check cooling circuit (coolant level, leak tightness,
kinks, guide, connections, closure).
value).
times if necessary.
Check the wear parts of the plasma torch.
Switch the machine off and on. If the error persists, no-
tify Service.
Switch the machine off and on.
If the error persists, notify Service.
Inform service.
Check the welding process.
Inform service.
Check the external shutdown devices. Check jumper
JP 1 on PCB T320/1.
Check the auxiliary drive (tacho – no signal, M3.51 de-
fective > notify Service).
Replace component.
