Display
099-000140-EW501
30.01.2024
Setting/selection
TIG antistick
-------function active (factory setting).
-------function inactive.
Program 0 block
With machines with access block, program 0 can be disabled. When the access block
has been enabled, programs 1–x only can be switched.
-------All programs can be selected (ex works)
-------Programs 1–x can be selected (program 0 disabled)
Show warnings
-------Function disabled (ex works)
-------Function enabled
Machine configuration (second part)
Settings for machine functions and parameter display
Start ramp
-------The welding current ramps up to the preset main current (factory setting)
-------The welding current jumps immediately to the preset main current
Responsiveness
-------Linear responsiveness
-------Logarithmic responsiveness (factory setting)
Tungsten balling with RT AC remote control
-------Function disabled
-------Function enabled (in addition, the "AC balance" rotary knob at the RT AC re-
mote control has to be turned to the left stop) (ex works)
Tungsten balling (old variant)
-------Function enabled
-------Function disabled (ex works)
Welding current polarity switching
-------polarity switching at the RT PWS 1 19POL remote control (ex works)
-------polarity switching at the welding machine control
spotmatic operating mode > see 5.2.6.4 chapter
Ignition by contact with the workpiece
-------Function enabled (ex works)
-------Function disabled
Setting the spot time > see 5.2.6.4 chapter
-------Short spot time
-------Long spot time
Process activation setting > see 5.2.6.4 chapter
-------Separate process activation (ex works)
-------Permanent process activation
Torch cooling mode
-------Automatic operation (ex works)
-------Permanently enabled
-------Permanently disabled
Welding torch cooling, post-flow time
Setting 1–60 min. (ex works 5 min.)
Time-based power-saving mode > see 5.7 chapter
Time to activation of the power-saving mode in case of inactivity.
Setting = disabled or numerical value 5-60 min..
Operating mode switching via interface for automated welding
------Non-latched
-------Special non-latched
Design and function
Machine configuration menu
