●Flow rate/Analogue output
Analogue output is output according to the controlled flow rate.
Voltage output (1 to 5 V)
Current output
Voltage output (0 to 10 V)
1: Set the current that flows from the connected equipment to the analogue output to 20 μA or less when selecting 0 to 10 V.
When more than 20 μA current flows, it is possible that the accuracy will not be satisfied below 0.5 V.
Model Min. value of the rated control flow rate
PFCA710
PFCA725
PFCA750
PFCA711
0 L/min
PFCA710/750/711
1 V
4 mA
0 L/min
PFCA710/750/711
*1
0 V
0.1 L/min
0.2 L/min
0.5 L/min
1.0 L/min
A
PFCA725
1.04 V 1.032 V
4.16 mA 4.128 mA
C
PFCA725
0.1 V 0.08V
Max. value of the rated control flow rate
100.0 L/min
-78-
B
5 V
20 mA
D
10 V
10.0 L/min
25.0 L/min
50.0 L/min
No.PF※※-OMA1002
