SMC Networks PFCA7 Series Operation Manual page 25

(2) Reference condition settings
Select [Fluid cond].
Press the UP or DOWN button
to select an item.
STD: Standard condition (Flow rate converted into volume at a temperature of 20° [C],
absolute pressure of 101.3 [kPa], and humidity of 65 [%R.H.])
NOR: Normal condition (Flow rate converted into volume at a temperature of 0° [C],
absolute pressure of 101.3 [kPa], and humidity of 0 [%R.H.])
(3) Display unit settings
Select [Unit].
Press the UP or DOWN button
to select an item.
: A product with no units selection function (fixed to SI units) does not indicate the display unit [cfm].
Press the SET button.
Press the SET button.
Returns to the [F0 System] settings.
Press the SET button.
Press the SET button.
Returns to the [F0 System] settings.
-25-
No.PF※※-OMA1002
