SMC Networks PFCA7 Series Operation Manual page 15

○IO-Link status and displayed content
Communication IO-Link
with master status
Yes
No
Light is OFF
○IO-Link communication indication
Contents indicated
DS read
DS write
BP read
BP write
Factory reset
Zero clear
Accumurate reset
Peak/Bottom clear
Application reset
: When the operation is completed, the display will return to normal.
Status
Operate
Normal
Start up
Preoperate
IO-Link
Version does
mode
not match
Error
Communication
shut-off
SIO mode
Data storage uploading
Data storage downloading
Block parameter uploading
Block parameter downloading
Receiving Restore Factory Reset
Receiving Zero Clear
Receiving Accumulate Reset
Receiving Peak Bottom Reset
Receiving Application Reset
-15-
Displayed content
communication status
(Output PD disabled)
communication status
(Output PD enabled)
At the start of
communication
IO-Link version does
not match with master
communication was
not received (for more
than 1 second).
General switch output
Content
No.PF※※-OMA1002
Content
Normal
Normal
Normal
