■Factory default setting
No
Function
[F0]
System settings
[F1]
OUT1 settings
Measurement
[F10]
settings
Analogue output
[F22]
settings
Accumulated flow
[F30]
(rate) settings
[F80]
Display settings
[F81]
PIN code settings
[F91]
Device information
[F96]
Input check
[F98]
Output check
Reset to factory
[F99]
default settings
Control Selection
-
Setting Mode
Item
[Fluid] Fluid settings
[Fluid cond] Flow rate reference condition
setting
[Unit] Flow rate display unit setting
[I/O type] Switching between the NPN
and PNP output
[IO-Link] IO-Link enable/disable setting
[PD invalid] Output PD setting at
communication error
[Mode] Output mode selection
[tol(P1)] Limit deviation tolerance setting
[OnDelay1] ON delay time setting
[OffDelay1] OFF delay time setting
[Resolution] Display resolution setting
[Type] Analogue output switching setting
[Free span] Analogue free range setting
[Save intvl] Accumulation storage setting
[Disp mode] Accumulated display
direction setting
[Auto shut] Automatic accumulation
shut-off enable/disable
[Colour] Selection of measurement value
display colour
[Display] Display OFF setting
[Rotation] Display rotation angle setting
[Brightness] Display brightness setting
[Line name] Line name display setting
Selection of PIN code
-
-
-
-
[Ctrmode] Flow rate control command
method setting
Default setting
[Air] Air
[STD] Standard condition
[L/min] L/min (L)
[PNP] PNP output
[Enable] Enable
[Shut off] Output PD: 0
[Tolerance] Limit deviation tolerance
mode
[ 3 %] 3% of rated control flow
[0.00 s] 0 second
[0.00 s] 0 second
[Low] 100 resolution
[1-5V] 1 to 5 V
(Analogue voltage type)
[4-20mA] 4 to 20 mA
(Analogue current type)
: The setting cannot be changed for
the analogue current type.
[10.00L/min] 10 L/min
(For the PFCA710, the upper limit of the
rated control flow.)
[No save] Not to hold
[Increment] Addition direction
[Disable] Disable
[1onB,offR] ON: Blue; OFF: Red
[ON] Display ON
[0deg] Rotation angle 0°
[100%] Brightness 100%
[OFF] No line name displayed
[OFF] Not used
Information check (No settings)
Input check (No settings)
[Normal] Normal output
[ oFF] Not to be reset
[Remote] Analogue input or
IO-Link communication
-23-
Page
Page
24
Page
28
Page
32
Page
33
Page
35
Page
37
Page
41
Page
42
Page
43
Page
44
Page
47
Page
48
No.PF※※-OMA1002
