■[F96 Input check] Checking input signal
The input signal can be checked.
<Operation>
Operate the UP or DOWN button in function selection mode to select [F96 Input check].
Analog: Analogue input voltage or analogue input current
PD output: Process data output ("- - -" in SIO mode)
Tcyc ave: Cycle time measurement ("- - -" in SIO mode)
Tcyc set: Cycle time setting ("- - -" in SIO mode)
Completion of the [F96 Input check] input signal check
