Optical Modules and Specifications

We provide appropriate optical modules according to the port types. You can select the
module to suit your specific needs. The optical module types and corresponding
specifications are provided for reference.
Table 7-4 SFP Modules and Specifications
Wavelength
(nm)
1310 Tx/1550
Rx
Table 7-5 SFP Module Cabling Specifications
Port Type
LC
Caution
For optical modules with a maximum cabling distance of over 40 km (including 40

km), install an optical attenuator to avoid overload when using short-distance SMFs.
The optical module is a laser device. Please do not look into the laser beam directly.

To keep the optical module clean, make sure that the unused ports remain capped.

Table 7-6 Pairing Description of the BIDI Optical Module
Rate/Distance
1000M/0.3 km
Fiber
DDM
Type
Not
SMF
supported
Fiber Type
SMF
Intensity of
Transmitted Light
(dBm)
Min. Max.
–9 –3
Core Specification
(μm)
9/125
Pairing Model
TSB-3GM3-35DCR (1310/1550)
43
Appendix
Intensity of
Received Light
(dBm)
Min. Max.
N/A –18
Max. Cabling Distance
0.3 km
