Hardware Installation and Reference Guide
7.4
Power Adapter Specifications
The AP uses a phoenix connector for power supply. Input voltage: 48 V DC; rated current:
0.5 A
Table 7-7
DC Power Adapter Terminal Specifications
Distance
Between
Holes
3.81 mm
Figure 7-5
Phoenix Connector
Terminal
Insertion
Width
Depth
8.42 mm
6.8 mm
Polarity
Reverse connection is supported. It
is recommended that the positive
pole is on the left, and the negative
pole is on the right.
45
