Hardware Installation and Reference Guide
RF Specifications
Antenna Gain
Max. Transmit
Power
Transmit Power
Adjustment
Modulation Modes
Receiving Sensitivity
RG-MAP852-SF-M
2.4 GHz: 2.22 dBi
5 GHz: 6.45 dBi
20 dBm
Note: The transmit power varies based on the regulations in
different countries and regions.
Configurable in increments of 1 dBm
IEEE 802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
(dedicated extensibility)
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
(dedicated extensibility)
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM,
4096-QAM (dedicated extensibility)
802.11b: –91 dBm (1 Mbps), –90 dBm (5 Mbps), –87 dBm (11
Mbps)
802.11a/g: –89 dBm (6 Mbps), –82 dBm (24 Mbps), –78 dBm (36
Mbps), –72 dBm (54 Mbps)
802.11n: –85 dBm @ MCS0, –67 dBm @ MCS7
802.11ac HT20: –85 dBm (MCS0), –60 dBm (MCS9)
802.11ac HT40: –82 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT80: –79 dBm (MCS0), –53 dBm (MCS9)
802.11ax HE80: –79 dBm (MCS0), –52 dBm (MCS11)
802.11ax HE160: –75 dBm (MCS0), –48 dBm (MCS11)
9
Product Introduction
