Indicators and Buttons

Note
The LED description applies to both fit and fat modes unless otherwise specified.
Table 1-9 System Indicator Status
Indicator Status
Off
Steady green
Steady red
Quick off after
blinking red
Blinking green at
an interval of 0.2s
Quick off after
blinking green
Blinking red at an
interval of 0.2s
Frequen
Description
cy
The AP is not powered on.
N/A The AP is powered on, but the indicator is manually
turned off.
N/A The software system of the AP is being initialized.
The system is running properly, but the uplink
N/A
service port is linked down.
On for 3s
In fit mode, the setup of a CAPWAP tunnel between
the AP and AC timed out.
Off for 1s
On for
0.2s
In fit or MACC mode, the software system of the AP
is being updated.
Off for
0.2s
On for 3s
The system is running properly.
Off for 1s
On for
0.2s
In fit mode, the AP is being located.
Off for
0.2s
