Hardware Installation and Reference Guide
Dimensions and
Weight
Mounting Hole
Pattern
Mounting Hole
Diameter
1.4.2

RF Specifications

Table 1-6 RF Specifications
RF Specifications
Radio Design
Operating Band
Transmission Rate
Antenna Type
RG-MAP852-SF-M
60 mm (2.36 in.)
5.1 mm (0.20 in.)
RG-MAP852-SF-M
Bi-radio
Up to four spatial streams
Radio 1: 2.4 GHz, 2 spatial streams: 2 × 2, MU-MIMO
Radio 2: 5 GHz, 2 spatial streams: 2 × 2, MU-MIMO
Radio 1:
802.11b/g/n/ax, 2.400–2.4835 GHz
Radio 2:
802.11a/n/ac/ax, 5.150–5.350 GHz
802.11a/n/ac, 5.470–5.725 GHz, 5.725–5.850 GHz
Note: The operating bands vary in different countries.
Radio 1: 2.4 GHz, 574 Mbps
Radio 2: 5 GHz, 2.402 Gbps
Maximum access rate of the AP:
2.4 GHz+5 GHz, 2.976 Gbps
Built-in omnidirectional antenna
8
Product Introduction
