evertz 9025TR Series Instruction Manual

Film footage encoders
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© Copyright 2001, 2002, 2006, 2007
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario, Canada
L7L 5Z9
Phone:
905-335-3700
Sales Fax:
905-335-3573
Support Fax:
905-335-0909
Internet:
Sales: sales@evertz.com
Tech Support: service@evertz.com
Web Page:
Version 1.3 January 2007
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 9025TR Series Film Footage Encoders. Evertz Microsystems
expressly prohibits the use of this manual for any purpose other than the operation of the device.
All rights reserved. No part of this publication may be reproduced without the express written permission of
Evertz Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.
9025TR Series
Film Footage Encoders
Instruction Manual
http://www.evertz.com
