evertz 2430RX-J2K-IP Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© Copyright 2014
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario,
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 0.1, July 2014
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 2430RX-J2K-IP. Evertz Microsystems expressly prohibits the use of
this manual for any purpose other than the operation of the 2430RX-J2K-IP.
development, features and specifications in this manual are subject to change without notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz
Microsystems Ltd. Copies of this manual can be ordered from your Evertz dealer or from Evertz Microsystems.
2430RX-J2K-IP Series
JPEG2000 to HDMI Converter
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571
Due to on going research and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2430RX-J2K-IP Series and is the answer not in the manual?

Questions and answers

Related Manuals for evertz 2430RX-J2K-IP Series

Summary of Contents for evertz 2430RX-J2K-IP Series

  • Page 1 Version 0.1, July 2014 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 2430RX-J2K-IP. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 2430RX-J2K-IP.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...

  • Page 5: Table Of Contents

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual TABLE OF CONTENTS OVERVIEW ........................... 1 GETTING STARTED ........................3 2.1. FRONT & REAR PLATE DESCRIPTION ................3 2.1.1. Video Connection ...................... 3 2.2. HARDWARE INSTALLATION ....................4 2.2.1. Inband Control Configuration ..................4 2.3.
  • Page 6 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.4. VIDEO PROC CONTROL WHEN +VPGC OPTION IS LICENSED ........23 6.5. INPUT MONITOR ....................... 25 6.6. PROGRAM MONITOR ....................... 27 6.7. ERROR MONITOR ......................29 6.8. NOTIFY ..........................30 6.9. PRODUCT FEATURES ...................... 32 FIRMWARE UPGRADE PROCEDURES ..................
  • Page 7 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 8 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual This page left intentionally blank Page iv Revision 0.1...

  • Page 9: Overview

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual OVERVIEW The 2430RX-J2K-IP is a versatile JPEG2000 to HDMI/DVI/DisplayPort processing converter. The 2430RX-J2K-IP is used in applications where delivery of J2K encoded video is to be displayed on a DVI/HDMI monitor. This self contained module accepts up to one JPEG2000 over IP streaming inputs. It decodes, processes and converts them on 1 output path to a DVI/ HDMI signal.

  • Page 10: Figure 1-1: Block Diagram

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Figure 1-1: Block Diagram Page - 2 Revision 0.1...

  • Page 11: Getting Started

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual GETTING STARTED 2.1. FRONT & REAR PLATE DESCRIPTION Figure 2-1: Front Plate POWER The 2430RX-J2K-IP comes with an auto-ranging DC voltage adapter that automatically senses the input voltage. Power should be applied by connecting a 3-wire grounding type power supply cord to the power entry module on the DC voltage adapter.

  • Page 12: Hardware Installation

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 2.2. HARDWARE INSTALLATION  Note: SFP’s must be ordered separately To successfully install the 2430RX-J2K-IP the user will require the following: 1. Unused IP address on the network or a DHCP server. 2. VistaLINK PRO Server IP address.

  • Page 13: Configuring Basic Network Settings

    PRO finds the card and confirms its configuration. ® Please consult your network administrator if you continue to have problems connecting the card with VistaLINK PRO, alternatively contact Evertz Microsystems Ltd. or your authorized reseller for technical ® support. Page - 5...

  • Page 14: Specifications

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual SPECIFICATIONS 3.1. TECHNICAL SPECIFICATIONS 3.1.1. Input • 2 x Female LC/UPC connectors supporting JPEG2000 3.1.2. Output • 1 x JPEG2000 to HDMI Converter • 2 x HDMI Output (mirror) • Supported resolutions: 525, 624, 720p, 59.94/5 Hz and VESA up to WUXGA (1920x1200) 3.1.3.

  • Page 15: Vistalink Pro Interface

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual VISTALINK PRO INTERFACE ® 4.1. CONTROL PORT CONTROL Figure 4-1: Control Port Tab  Note: There is only one physical control port on the unit, both IP’s come from the same Network Interface Card (NIC). This allows the unit to be controlled via multiple subnets on this port.

  • Page 16: Data Port Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 4.3. DATA PORT MONITOR Figure 4-3: Data Port Monitor Tab Port Link Status: This parameter returns the port status link, in either an ‘UP’ or ‘DOWN’ state. Port Link Info: This parameter returns the port link status (i.e. speed, duplex). Received Data Ethernet Total Bitrate: This field displays the bitrate received on this Ethernet port and is represented in kbps.

  • Page 17: Decoder Configuration

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual DECODER CONFIGURATION 5.1. DECODER INPUT CONTROL Figure 5-1: Decoder Input Control Tab Input Stream Active Input Stream State: This parameter will activate or deactivate this stream. By default, all streams are inactive. Once this parameter is set to active, traffic can run through it. Input Port Select: This parameter allows the user to set the physical interface to receive data from either data port 1 or data port 2.
  • Page 18 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Auto Program Select Mode: This control allows the user to set how the decoder will select a program for decoding when Program Tuning Mode is set to auto. • First Program in PAT: select audio PIDs from first program will be chosen. •...

  • Page 19: Decoder Output Control

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Reboot: Part of the decoder Output table, this variable allows the SNMP Manager to perform a remote reboot of the decoder. This is useful when the IP interface (and other) changes have been made, and a reset is needed to make them take affect.

  • Page 20: Video Proc If +Vgpc Option Is Licensed

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual SDI Audio Source This control allows the user to enable or disable which audio service will be embedded into the audio group for SDI/HDSDI output. NOTE: This configuration is the same for SDI Audio Sources 1 through Analog Audio Source This control allows the user to enable or disable the audio service which will be embedded into the audio group for Analog output.
  • Page 21 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Enable YCbCr Proc: This control will Enable or Disable the YCbCr processor block. Y Gain: This control allows the user to adjust the gain for the Y component in the YCrCb domain. Range for this value can be set from -100% to 100%. Y Offset: This control allows the user to adjust the DC offset of the Y component in =/- 200 quantization increments.

  • Page 22: Input Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 5.4. INPUT MONITOR Figure 5-4: Input Monitor Tab Input Stream Stream Type: This field displays the type of input stream as either Multicast or Unicast. Received Ethernet Bandwidth: This parameter displays the Ethernet bandwidth for the input stream, and can range from 0 to 1000000000 bits.
  • Page 23 Network ID: This parameter returns the value of the network ID read from the transport stream, and can range from 0 to 65535. PSD Service Type: This parameter returns the service type read from the Evertz private service descriptor (79) from the PMT. It provides an enumerated string as follows:...

  • Page 24: Program Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 5.5. PROGRAM MONITOR Figure 5-5: Program Monitor Tab Program Monitor Program Num in TS: This field displays the current program being decoded by the decoder. Range for this value can be from 0 to 65535. PMT PID: This parameter returns the PID for the PMT, for the program being decoded.

  • Page 25: Error Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Video Resolution: This field displays the current video resolution. Video Profile and Level: This field displays the current profile and level of the video stream. Video Chroma Format: This field displays the chroma format of video. Program Audio Monitor Audio PID Number This field displays the current PID which is carrying the PES for this audio stream.

  • Page 26: Notify

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Ancillary Error Monitor This field displays the number of Continuity Counter error incidents for Ancillary PIDs. PCR Error Monitor This field displays the number of Discontinuity Error incidents for PCR PIDs. Reset Counters This control will reset all the error counters.

  • Page 27: Web Interface

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual WEB INTERFACE 6.1. SYSTEM Figure 6-1: Web GUI System Tab NOTE: Configuration options are identical for both Ports 1 & 2 Control Port IP Address: This parameter allows the user define the IP address for the control port Control Port NetMask/Subnet: This parameter allows the user to define the Netmask/Subnet for the control port Control Port Gateway: This parameter allows the user to define the gateway address for the control...

  • Page 28: Decoder Input Control

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Port Link Status: This parameter returns the status link for data port 1, in either an ‘UP’ or ‘DOWN’ state. Received Data Ethernet Total Bitrate: This parameter displays the bit rate received on this Ethernet port is represented in kbps, and the value can range from 0 to 1000000000.
  • Page 29 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Input IP Address: This parameter allows the user to define the IP address/ Multicast address from which data will be received. Input IP Port Number: This parameter allows the user to select the input UDP port number, which can range from 1 to 65535.

  • Page 30: Decoder Output Control

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual VANC PID Select: This control allows the user to select the VANC PID which will be decoded. This control is only applicable when the Program Tuning Mode is set to Manual PID Select. Range for these values can be set from 2 to 8190.

  • Page 31: Video Proc Control When +Vpgc Option Is Licensed

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.4. VIDEO PROC CONTROL WHEN +VPGC OPTION IS LICENSED Figure 6-4: Web GUI Video Proc Control (1) Figure 6-5: Web GUI Video Proc Control (2) Page - 23 Revision 0.1...
  • Page 32 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Enable Video Proc: This control will Enable or Disable the video processor module. Enable YCbCr Proc: This control will Enable or Disable the YCbCr processor block. Y Gain: This control allows the user to adjust the gain for the Y component in the YCrCb domain. Range for this value can be set from -100% to 100%.

  • Page 33: Input Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.5. INPUT MONITOR Figure 6-6: Input Monitor Tab Stream Type: This parameter will display whether or not the current input stream is multicast or unicast. Received Ethernet Bandwidth: This parameter displays the Ethernet bandwidth for the input stream, and can range from 0 to 1000000000 bits.
  • Page 34 Network Name: This parameter returns the network name read from the transport stream. PSD Service Type: This parameter returns the service type read from the Evertz private service descriptor (79) from the PMT. It provides an enumerated string as follows:...

  • Page 35: Program Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.6. PROGRAM MONITOR Figure 6-7: Program Monitor Tab Program Num In TS: This parameter returns the actual program number that is being decoded. Range for this value can be from 0 to 65535. When in Manual PID Selection Mode no value will be displayed. PM TPID: This parameter returns the PID for the PMT, for the program being decoded.
  • Page 36 2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Video PID Num: This parameter displays the PID which carries the PES for Video. Range for this value can be from 0 to 8191. Video Bit Rate: This parameter displays the bit rate for the video elementary stream. Range for this value can be from 0 to 270000000.

  • Page 37: Error Monitor

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.7. ERROR MONITOR Figure 6-8: Error Monitor Tab Video Error Monitor Video CC Errors: This field displays the number of Continuity Counter error incidents for Video PID. Range for this value can be from 0 to 65535. Video CRC Errors: This field displays the number of CRC error incidents for Video.

  • Page 38: Notify

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual 6.8. NOTIFY Figure 6-9: Notify Tab (1) Page - 30 Revision 0.1...

  • Page 39: Figure 6-10: Notify Tab (2)

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Figure 6-10: Notify Tab (2) Figure 6-11: Notify Tab (3) The Notify tab allows the user to turn traps on or off, as well as the current status for all faults present. Page - 31 Revision 0.1...

  • Page 40: Product Features

    Product License: This parameter will display the product licence key. Product Serial Number: This parameter displays the card’s serial number, which is identical to the MIB control number. This value is also required to access this device via Evertz Product Support Services Webpage.

  • Page 41: Firmware Upgrade Procedures

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual FIRMWARE UPGRADE PROCEDURES 7.1. VISTALINK PRO UPGRADE Ensure that the 2430RX-J2K-IP is running the latest firmware, to check this simply right click on the cards address in VLPro Client and select Version Information. Figure 7-1: Version Information Drop-down menu This will open a window that displays all of the current version information loaded onto the 2430RX- J2K-IP.

  • Page 42: Figure 7-3: Apply Update Drop-Down Menu

    JPEG2000 to HDMI Converter User Manual To upgrade the firmware, locate the latest .jar files which can be found on the Evertz website. Open VLPro Client and navigate to the top tool bar. Locate the Help drop down menu and select Apply Update.

  • Page 43: Figure 7-4: Jar File Selection

    2430RX-J2K-IP JPEG2000 to HDMI Converter User Manual Figure 7-4: JAR File Selection When the window opens you want to select the latest .jar file for the 2430RX-J2K-IP, from its saved location on the computer and select Open. At this point the VLPro Server will send a message asking to Restart, select Yes. This will apply the update firmware to the 2430RX-J2K-IP.

  • Page 44: Web Interface Upgrade

    2430RX-J2K-IP card. If it is not upgrade the firmware using the latest .jar files which can be found on the Evertz website. Select Browse and locate the .jar file on the computer. Then select Upgrade, when the upgrade is complete the 2430RX-J2K-IP will Reboot to apply the firmware upgrades.
