Accessing The Management Processor Via A Web Browser; The Ls Command Screen - HP 9000 Integrity rp8440 Installation Manual

11. A screen similar to
Figure 2-35 The ls Command Screen
To return to the MP Main menu, enter ma.
To exit the MP, enter x at the MP Main Menu.

Accessing the Management Processor via a Web Browser

Web browser access is an embedded feature of the management processor (MP). The Web browser
enables access to the server via the LAN port on the core I/O card. MP configuration must be
done from an ASCII console.
NOTE:
The MP has a separate LAN port from the system LAN port. It requires a separate LAN
drop, IP address, and networking information from that of the port used by HP-UX.
Before starting this procedure, gather the following information:
• IP address for the MP LAN
• Subnet mask
• Gateway address
• Host name (this is used when messages are logged or printed)
To configure the LAN port for a Web browser, perform the following steps:
1. Connect to the MP using a serial connection.
2. Configure the MP LAN. See
3. Type cmto enter the Command Menu.
4. Type sa at the MP:CM> prompt to display and set MP remote access.
76 Installing the System
Figure 2-35 will display allowing verification of the settings.
"Configuring LAN Information for the MP".
