4.10

Removing hinging racks

1. Grasp the hinging rack in the middle of the upper level.
2. Press the hinging rack upwards (A).
3. Tilt the left hinging rack in the cooking cabinet (B).
4. Unhook the hinging rack and remove it from the cooking cabinet.
4.11

Integrated fat drain

If your unit is equipped with an optional integrated fat drain, the dripping fast is
collected in the cooking cabinet and fed into the grease drip container.
1 Ball valve handle
3 Filler neck with bayonet lock
1. Open the cooking cabinet door.
2. Remove the lock of the drain pipe.
Original instructions for use
4 | Working with the unit
2 Drain pipe
4 Grease drip container
33 / 188
