Chapter 3: Controller Connection Examples
Configure the Do-more! Designer Software to Access the BRX PLC via VPN
1. Open the BRX Do-more! Designer software on your PC and select "New Link" from the
Links panel on the lower left of the Launchpad tab.
2. Click the "Link Editor..." button.
3. Select the PLC family (Do-more! BRX Series in this example) and PLC Type.
4. Click the "Port" tab, select Ethernet and enter the BRX IP address defined previously
(192.168.140.19 in this example).
5. Enter a Name and Description for this PLC link, then click ACCEPT.
6. Double-click the new entry in the Links list to connect to the BRX PLC.
You should now be successfully connected to the BRX PLC from a remote PC through the VPN.
