Chapter 1: Hardware

Dimensions

units: mm [in]
ANTENNA PORT (MODELS THAT SUPPORT 4G)
ANTENNA PORT (MODELS THAT SUPPORT 4G OR WI-FI)
SNAPS TO
STANDARD DIN RAIL
(35X7.5 MM)
NOTE: Maintain 25mm [1 inch] clearance around device.

Compatible Accessories

SE-SL3011-4G, SE-SL3011-4GG and SE-SL3011-WF require antennas, purchased
separately. The routers that support 4G have two standard SMA screw antenna connectors
for 4G LTE antennas and the SE-SL3011-WF router contains an RP-SMA screw antenna
connector for a 2.4 GHz WiFi antenna.
NOTE: Two antennas will provide best performance, including improved and more predictable throughput and
improved resistance to interference. If only one antenna is connected to a 4G router, it must be connected to the
MAIN antenna connector, closer to the front of the router.
For compatible antennas, see Appendix A or visit www.AutomationDirect.com.
StrideLinx™ Cloud 2.0 Industrial VPN Routers User Manual
SIM CARD
SLOT 4G
11.9
0.47
55.5
2.19
116.1
111.0
4.57
4.37
55.5
2.19
StrideLinx router dimensions
95.0
3.74
USB PORT
100.8
3.97
1st Edition Rev. C
28.0
1.10
122.9
4.84
RJ45 PORT
TYPICAL
