AutomationDirect StrideLinx SE-SL3001 Quick Start Manual

Linx
S
tride
Connecting to your StrideLinx Router
1. Create your company account at
2. From your StrideLinx account create
a configuration file for the device at
App Menu ( ) > Fleet Manager > Tools >
Start Configuration.
This file will include any parameters needed
to connect the router to a WAN, WiFi
network, or LTE cellular service.
If you are using an LTE cellular model,
please be sure to register your SIM card.
In the StrideLinx configuration, please insert
the SIM card APN and PIN code for your
particular cellular service.
3. Save the configuration file to the root directory
of a USB flash drive and plug the drive into
your StrideLinx router. Ensure the file name is
router.conf; if it was created with a suffix, rename it
to router.conf.
4. Insert a SIM card (Models SE-SL3011-4G and
SE-SL3011-4GG only) and connect an antenna
or WAN Ethernet cable.
5. Power on the StrideLinx Router and wait for the configuration to be down-
loaded (indicated by the Status LED changing from solid red to blinking red).
6. Wait for the router to connect to the internet and register itself on the StrideLinx
Server (indicated by the Status LED changing to blinking blue then solid blue).
7. Once the router has registered itself on the server, it will appear in your
company account as a new device. Click its entry in the Devices list, enter a
name for the device and click ACTIVATE. When the device has been activated
and is online, a green icon will appear beside its entry in the Devices list.
8. To connect to the VPN from a PC, first download and install the VPN client,
located under App Menu ( ) > Fleet Manager > Tools > Download Installer.
9. After the VPN Client is installed, log in to your StrideLinx account, select the
device and click the CONNECT button to securely connect to it.
StrideLinx Server
L ™ i
inx ndustriaL
https://www.StrideLinx.com and log in.
N : A SIM
ote cArd ANd dAtA plAN Are
4G lte . A
requIred for operAtIoN
W f 4G
requIred for I I ANd ModelS ANd MuSt
reMAIN coNNected durING operAtIoN
WArNING: do Not
INSert or reMove the
SIM
cArd WheN poWer IS ApplIed to the
.
router
VPn r
StrideLinx Industrial VPN Router Models
Part Number
SE-SL3001*
SE-SL3011
SE-SL3011-WF
SE-SL3011-4G (AT&T)
SE-SL3011-4GG (global)
* SE-SL3001 does not support data logging or notifications.
Power Wiring
The StrideLinx router can be powered from the same DC source that is used to
power your other devices. To maintain the UL listing, this must be a Class 2 power
supply. A DC voltage in the range of 12 to 24 VDC needs to be applied between the
V+ terminal and the V- terminal as shown below. A recommended DC power supply
is AutomationDirect.com part number PSL-24-030. The Shield terminal must be
connected to the ground conductor with minimum 16 AWG copper wire.
Terminal block connector is Weidmuller BL 5.08/04/180 SN BK BX or equivalent.
Wiring Details
Terminal screw torque
Wire Size Range
Max Wire Length
Wire Strip Length
Digital Input (DI1)
A software-configurable Digital Input is provided to allow local control of access to
NteNNA
the router.
.
Type
DI Voltage Range
DI OFF State Voltage Range
DI ON State Voltage Range
DI ON State Current Range
SIM Card
(#SE-SL3011-4G and SE-SL3011-4GG only)
Insert the SIM card into the slot until you feel a click, then release. SIM card should
be flush with the enclosure.
To remove, press until you feel a click, then release. SIM card will partially eject.
Never insert or remove the SIM card when power is applied to the router.
1
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
outer
Gigabit Ethernet WiFi
ü
ü ü
ü
DI1
3.5 lb-in (0.4 N·m)
Shield
18–12 AWG
3m (9.84 ft)
V+
7mm
Digital Input Details
Optocoupler
0–29 VDC
0–3 VDC
7–29 VDC
2–5 mA (typically)
Front Panel LEDs
Reset
SIM Card Slot
Front Panel LEDs
Antenna
Connector
LED State
Terminal Block
ACT ON, Blue
Connector
USB Blinking, Blue
Configuration
ON, Red
Port
Signal LED
Blinking, Red
ACT LED
Signal ON, Blue
Ethernet
Port LED
(typical)
ON, Purple
ON, Red
Blinking, Blue
Blinking, Red
Ethernet ON, Blue
Blinking, Blue
4G LTE
ü
Digital Control Signal
+ -
V-
+ -
12–24 VDC
Description
Connected
Connecting
Booting/
not yet registered
System alarm,
see manual
Connected,
good reception
Connected,
medium reception
Connected,
poor reception
Initializing
Invalid PIN or PUK
Link up
Data activity
