Chapter 1: Hardware

Operation

LED Status Indicators

The StrideLinx router has two LEDs for router status, and one LED per Ethernet port.
StrideLinx™ Cloud 2.0 Industrial VPN Routers User Manual
Signal LED (SE-SL3011-4G, -4GG & -WF models)
Color
Red
Red
Red
Purple
Blue
Blue
Signal LED
Color
ACT LED
Red
Red
Ethernet
Port LED
Red
(typical)
Red
Red
Blue
Blue
Blue
1. The network range on the LAN side is in conflict with the settings on the WAN side. The
router cannot reliably access the internet because of this. Changing the LAN side IP range
generally resolves the conflict.
2. If you want to access the device again, you will have to reconfigure it via a USB stick.
3. This means someone removed the router from the company after registration without
performing a factory reset. Fix this by performing factory reset and configuring the router.
Color
Blue
Blue
Mode
Blinking continuously
Blinking 2 pulses SIM card invalid, PIN invalid or PUK required
Constant
Constant
Constant
Blinking
ACT LED
Mode
Constant
Blinking 1 pulse
Blinking 3 pulses
Blinking 4 pulses The router was removed from the StrideLinx
Blinking 5 pulses The router was already registered to the
Blinking 1 pulse
Blinking 2 pulses
Constant
Ethernet activity LEDs
Mode
Constant
Blinking
1st Edition Rev. C
Description
No reception
Low reception
Medium reception
Good reception
Initializing
Description
Booting or not registered
Waiting for internet access
LAN/WAN conflict
1
Cloud
2
StrideLinx Cloud
3
Connecting to StrideLinx Cloud
Setting up VPN connection
VPN connection active
Description
Link up
Data activity
1-11
