Appendix A: Accessories & Add-on Licenses

Antennas

The WiFi and 4G LTE variants of the StrideLinx VPN Router require external antennas to
improve signal strength. The 4G LTE antennas use a standard SMA screw antenna connector,
and the WiFi antennas use an RP-SMA screw antenna connector.
Several antenna options are available, as follows.
4G LTE Antennas (for P/N SE-SL3011-4G and SE-SL3011-4GG)
STRIDE 4G LTE antennas are available in three versions, providing direct connection,
magnetic mount, and panel mount options.
Note: Two antennas will provide best performance, including improved and more predictable
throughput and improved resistance to interference. If only one antenna is connected to the
router, it must be connected to the MAIN antenna connector, closer to the front of the router.
STRIDE whip/tilt LTE
antenna, connector
mount.
Fits
Antenna Connector
Application
Impedance
Antenna Type
Cable Length
Frequency Range
Gain
Height
IP Rating
Maximum Power
Mounting Screw Torque
* Gains listed are based on the antenna being mounted on a suitable ground plane.
StrideLinx™ Cloud 2.0 Industrial VPN Routers User Manual
STRIDE whip/straight
LTE antenna, magnetic
base mount, 9.8ft/3m
cable length.
4G LTE Antenna Specifications
SE-ANT110
SE-SL3011-4G and SE-SL3011-4GG
whip, tilt
N/A
700–960MHz / 1.71–3.8 GHz
-3.0 dBi / 0.9 dBi
2.84 in
–
10W
NA
STRIDE dome LTE antenna,
IP67, panel mount,
9.8ft/3m cable length.
SE-ANT130*
SMA (M)
LTE, CDMA, GSM, HSPA, UMTS
50Ω
whip, straight
3m [9.8 ft]
700–960MHz / 1.71–3.5 GHz
-2.5dBi / 0.1dBi
13 in
–
50W
NA
1st Edition Rev. C
SE-ANT150
dome
3m [9.8 ft]
700–960MHz / 1.71–2.7 GHz
1.2 dBi / 3.2 dBi
1.89 in
IP67
5W
2.94 N·m
A-2
