Chapter 2: StrideLinx Cloud 2.0
Getting Started:
Using a cellular connection (Part # SE-SL3011-4G and SE-SL3011-4GG only)
The StrideLinx VPN Router will be connected to Stridelinx Cloud 2.0
using a 2.4 GHz wireless LAN connection to an access point on your
company network.
Before you begin this step
• Required info: provider's APN (access point name) and SIM card's PIN code. The APN
is established by your service provider.
• Make sure the SIM card has sufficient internet credit
• Make sure that it is activated (contact your provider if necessary)
Create a configuration file
A configuration file wizard in StrideLinx Cloud 2.Fleet Manager will guide you through
creating the configuration file. The wizard is pre-populated with commonly used settings to
simplify the process.
1. Go to the Fleet Manager, which is accessible via the Apps menu
corner when logged into your StrideLinx account.
2. Open the main menu
configuration] on the Router config file card.
3. Select the connection type "Cellular network".
4. Enter the provider's APN and the SIM card's PIN code (if applicable).
5. When using a cellular connection, the IP address and DNS server will be automatically
assigned via DHCP, and HTTP Proxy will be disabled.
6. Local control over remote accessibility, if enabled, will allow you to enable/disable the
VPN connection via a wired digital input on the router. Wiring details are in Chapter 1.
7. Enter a unique IP address for the LAN side of the router (machine network). Only
the router's IPv4 IP address needs to be entered now. After the router is connected to
StrideLinx Cloud 2.0, additional settings can be configured.
8. Click [Download file] to download the generated file and save it to the root directory of
a USB flash drive. Note that the filename on the USB drive must be exactly router.conf
with no added characters, in case your browser added a suffix.
You can now skip ahead to the
StrideLinx™ Cloud 2.0 Industrial VPN Routers User Manual
Create an
account
Config file
Standard APNs: AT&T: m2m.com.attz
* See Chapter 1 for more information on setting up your SIM card and cellular service.
Set up your
Router
Register
T-Mobile: fast.t-mobile.com
, select Tools in the left menu, and select [Start
Register your router step on page 2-12.
Connect to your
Machine
Activate
Online Help
Verizon*: vzwinternet
in the top right
1st Edition Rev. C
2-11
