Chapter 2: StrideLinx Cloud 2.0
Update Router Settings (cont'd)

LAN (Machine Network) Settings

DHCP Server
The StrideLinx router has it's own DHCP server that automatically
assigns an IP address, and other necessary network parameters, to clients
connected to the router's LAN ports if they do not have a static IP address configured.
The DHCP server is enabled by default, but can be disabled if necessary. It also automatically
changes along with other changes you make. If you change the IP range of the router's LAN
IP address, then the IP range of the DHCP server will automatically change as well.
Follow these steps if you want to manually change the DHCP server settings:
1. In the Fleet Manager menu, select Devices
2. If your machines are all assigned static IP addresses, you an uncheck
[Assign IP addresses automatically].
3. Otherwise, enter a range of IP addresses to be assigned by the router. The range must be
within the local subnet as defined by the router LAN IP and network mask.
4. Click the dropdown arrow beside [Push config to device] in the upper right of the
screen, and select [Import config from device].
5. Address Reservations: To reserve specific IP addresses for certain machines, add the
MAC address and reserved IP address for each machine.
6. You have now made the changes in StrideLinx Cloud, but these are not yet active in your
device. Click [Push config to device] in the top right corner for them to take effect.
Source NAT
Source NAT is the translation of the source IP address of a packet leaving the router. It should
generally be left enabled. When disabled, each machine that is connected to the router must
have a default gateway set up.
StrideLinx™ Cloud 2.0 Industrial VPN Routers User Manual
, then click the name of your router.
1st Edition Rev. C
Online Help
2-21
