Rectifying faults

All products are subject to rigorous production checks and final checks. If, despite this, something fails to
work at any time, please check the product using the following flowchart. If none of the fault rectification
procedures described leads to the correct functioning of the product, please inform your authorised dea-
ler.
7.1

Warnings

Depending on the display options of the machine display, a warning message is displayed as follows:
Display type - machine control
Graphic display
two 7-segment displays
one 7-segment display
The cause of the warning is indicated by a corresponding warning number (see table).
• In case of multiple warnings, these are displayed in sequence.
• Document machine warning and inform service personnel, if required.
Warning
1 Excess temperature
2 Half-wave failures
3 Torch cooling warning
4 Shielding gas
5 Coolant flow
6 Wire reserve
7 CAN bus failure
8 Welding circuit
9 WF configuration
10 Partial inverter
11 Excess temperature of the
coolant
12 Welding monitoring
13 Contact error
14 Alignment error
15 Mains fuse
16 Shielding gas warning
17 Plasma gas warning
18 Forming gas warning
19 Gas warning 4
099-00T501-EW501
1.8.2022
Potential cause / remedy
A shutdown is imminent due to excess temperature.
Check process parameters.
Check coolant level and top up if necessary.
Check shielding gas supply.
Check min. flow rate.
Only a small amount of wire is left on the spool.
Wire feeder not connected; automatic circuit-breaker of wire
feed motor (reset the tripped automatic circuit-breaker by actua-
ting).
The inductance of the welding circuit is too high for the selected
welding task.
Check WF configuration.
One of several partial inverters is not supplying welding current.
Check temperature and switching thresholds.
[1]
The actual value of a welding parameter is outside the specified
tolerance field.
The resistance in the welding circuit is too high. Check earth
connection.
Switch the machine off and on. If the error persists, notify Ser-
vice.
The power limit of the mains fuse is reached and the welding
power is reduced. Check the fuse setting.
Check the gas supply.
Check the gas supply.
Check the gas supply.
reserved
Display
[2]
Rectifying faults
Warnings
