5.2.6

Pulse welding

5.2.7

Average value pulse welding

Average value pulse welding means that two currents are switched periodically, a current average value
(AMP), a pulse current (Ipuls), a balance (
predefined ampere current average value is decisive, the pulse current (Ipuls) is defined by the
meter as a percentage of the current average value (AMP). The pulse pause current (IPP) requires no
setting. This value is calculated by the machine control, so that the welding current average value (AMP)
is maintained at all times.
AMP = Main current; e.g. 100 A
Ipuls = Pulse current =
IPP = Pulse pause current
Tpuls = Duration of one pulse cycle = 1/
= Balance
5.2.8

Arc length restriction (USP)

The arc length restriction
tected (unusually large gap between electrode and workpiece). The function can be switched on or off
depending on the process > see 5.9 chapter.
5.3

JOB favourites

Favourites are additional locations for storing and loading frequently used welding tasks, programs and
their settings. The status of the Favourites (loaded, changed, not loaded) is indicated by signal lights.
• Five Favourites are available to save any settings.
• As required, the access control can be adjusted with the key switch or Xbutton function.
Item Symbol
1
2
099-00T501-EW501
1.8.2022
x AMP; e.g. 140% x 100 A = 140 A
function stops the welding process when an excessive arc voltage is de-
Description 0
push-button - JOB Favourites > see 5.3 chapter
•-----------Pressing the push-button briefly: Loading Favourites
•-----------Press and hold the push-button (>2 s): Saving as a Favourite
•-----------Press and hold the push-button (>12 s): Deleting a Favourite
Signal light of Favourite status
---------- Signal light is green: Favourite loaded, settings of the Favourite and the cur-
rent device settings are identical
---------- Signal light is red: Favourite loaded, but settings of the Favourite and the cur-
rent device settings are not identical (for example, the operating point has
been changed)
------------ Signal light is off: Favourite not loaded (e.g. JOB number has been changed)
Functional characteristics
) and a frequency (
Figure 5-35
; e.g. 1/1 Hz = 1 s
Figure 5-36
JOB favourites
) having been defined first. The
para-
49
