Control Section C - EWM T5.01-DC Comfort 3.0 Operating Instructions Manual

Machine control – Operating elements
Overview of control sections
4.1.3

Control section C

Item Symbol
1 I
1
2 t
up
3 I
st
4
5
6
7 JOB
8 t
st
9
10
11 t
1
12
13 t
2
14
15
16 t
ed
17
18 I
ed
19 t
dn
20
Description 0
Signal light for main current
Signal light for up-slope time
Signal light for start current
Signal light for electrode diameter
Gas pre-flow time signal light
Signal light for ignition optimisation (TIG)
Signal light for welding task (JOB)
Signal light for start current time
Signal light activArc
Signal light for balance
Signal light for pulse time
Signal light for frequency
Signal light for pulse time
Signal light for Arcforce (welding characteristics) > see 5.2.4 chapter
Signal light for the welding program > see 5.1.5 chapter
Display of the current program number in the welding data display.
Signal light for end current time
Gas post-flow time
Signal light for end current
Signal light for down-slope time
Figure 4-4
/pulse current
> see 5.1.8 chapter
