EWM T5.01-DC Comfort 3.0 Operating Instructions Manual page 19

Item Symbol
13 Hold
14
15
16
17
18
19
20
21
22 VRD
099-00T501-EW501
1.8.2022
Machine control – Operating elements
Description 0
Signal light Status display
After each completed welding task, the last values used in the welding process for the
welding current and welding voltage are shown on the displays, and the signal light will
be on
Access control active signal light
Signal light is on when access control is active on the machine con-
trol > see 5.6 chapter.
Without function in this machine version.
Signal light welding voltage
Illuminates when the welding voltage is displayed in volts.
Without function in this machine version.
Without function in this machine version.
Signal light display value in units of kilowatts
Signal light - display value in Inches per minute
Signal light - display value in metres per minute
Voltage reduction device (VRD) signal light > see 5.7 chapter
Overview of control sections
