Finish: Spectra 64000 Library
4. Using an appropriate screwdriver, tighten the five screws that hold the swinging
drive slot door to the robotic rack assembly (Figure 46).
5. Plug in the 25-wire black connector at the bottom front of the robotic rack assembly
(Figure 47).
6. Replace the drives in their proper slots.
7. Close the library door.
8. Secure the library lock with the Spectra 64000 library door key.
9. Proceed to Reconnect the Library and the Host System on page 46.
Figure 46 Replace the screws in the drive slot door.
Figure 47 Plug in the 25-wire black connector.
