Finish: Spectra 12000 Library

1. Plug in the 25-wire black connector to the bottom front of the robotic rack assembly,

taking care not to bend the pins inside of the connector.

Note:

Before proceeding, note whether you have a swinging drive slot door

(with screws attaching it to the robotic rack assembly) or a stationary

drive slot assembly. If it is stationary, proceed directly to Step 6.

2. If your drive slot assembly has a swinging door, swing the drive slot door closed

(Figure 24).

Figure 23 Plug in the 25-wire black connector.

Figure 24 Close the drive slot door.

60-Slot Segment Upgrade Guide
