Install the Magazines
9. Insert the next magazine (one with a yellow label) into the yellow-coded niche next
to the red-coded niche—the niche next to the segment you just installed (Figure 37).
The tabs on the magazines should overlap and fit together.
Note:
Make sure that the tape slot marked with the number 1 is at the top of the
magazine before placing each magazine into the library.
Figure 37 Clip the second magazine firmly into
place (view as would be seen from the front door,
installing from the back of the library forward).
