Prepare the Spectra 64000 Library
6. Pull open the swinging drive slot door (Figure 29).
7. Using an appropriate screwdriver, unscrew the three screws that hold the top of the
robotic rack assembly to the chassis (Figure 30).
8. Unscrew the two screws that hold the bottom of the robotic rack assembly to the
chassis.
30 60-Slot Segment Upgrade Guide
Figure 29 Open the swinging drive slot door.
Figure 30 Remove the screws that attach the robotic
rack assembly to the chassis.
