Install the Magazines
9. Install the other magazine with a yellow label in the next yellow-coded niche—the
next niche closer to the front of the library (Figure 15). The tabs on the magazines
should overlap and fit together.
10. Lastly, install the magazine with the blue label into the blue-coded niche—the niche
closest to the front of the library. The tabs on the magazines should overlap and fit
together.
Figure 15 Clip the third magazine firmly into place.
