Finish: Spectra 64000 Library

1. Using an appropriate screwdriver, tighten the two screws that hold the bottom of the

robotic rack assembly to the chassis.

2. Use an appropriate screwdriver to tighten the three screws that hold the top of the

robotic rack assembly to the chassis (Figure 44).

3. Close the swinging drive slot door (Figure 45).

Note:

If you have a stationary drive slot panel, proceed directly to Step 5.

60-Slot Segment Upgrade Guide

Figure 44 Replace the screws which attach the

robotic rack assembly to the chassis.

Figure 45 Close the swinging drive slot door.
