Remove the Rail-Mounted Robotic Rack Assembly

1. Remove the four (captive or flush-mount) screws that hold the robotic rack assembly
in the chassis (Figure 6).
Figure 6 Location of the four screws in the chassis.
2. Carefully slide the robotic rack assembly outward until it locks (Figure 7).
Figure 7 Slide the robotic rack assembly outward.
60-Slot Segment Upgrade Guide 11
