Remove the Carbon-Top Robotic Rack Assembly

1. Remove the five flush screws that hold the robotic rack assembly in the chassis
(Figure 9).
2. Carefully slide the robotic rack assembly outward (Figure 10).
Warning:
The robotic rack assembly has no locks to secure it to the library. If you
slide the assembly out too far, there is a danger that the assembly will
fall out or tip the library. Use care when sliding the assembly outward.
Figure 9 Location of the five screws in the chassis.
Figure 10 Slide the robotic rack assembly out of
the library, using care not to pull it out too far.
