Prepare the Spectra 64000 Library
4. Using an appropriate screwdriver, remove the five screws that hold the swinging
drive slot door to the robotic rack assembly (Figure 27).
Note:
If the drive slot assembly has no screws attaching it to the picker
assembly, then it is a stationary door, and you will not need to move the
door or the drives to perform the slot segment upgrade. If you have a
stationary door, simply skip this step, as well as Step 6.
5. Unplug the 25-wire black connector at the bottom front of the robotic rack assembly
(Figure 28).
Figure 27 Remove the screws holding the swinging
drive slot door to the robotic rack assembly.
Figure 28 Unplug the 25-wire black connector.
